XGZP6161 Pressure Transducer
Feature
Firm construction,Easy installation
0.5-4.5V output,Perfect performance.
Advanced Anti-interference,wave protection
Prefect Anti-shock,anti-overload,corrosion-resistant
Isolation Diaphragm,Ceramic Sensor element
Low cost for high volume application
Applications
Water pump,frequency-alterable constant voltage water supply,building automatic control, Water Treatment system,Hydraulic pressure monitoring etc,.
HVAC controlling(Heating, Ventilation and Air Conditioning),Air conditioner,Refrigeration, process controlling,hydraulic pressure monitoring ,etc.
Other pressure measure and control of petroleum,chemi-industry,metallurgy,power station, hydrology.etc,.
Introduction
XGZP6161 Pressure Transducer is high performance and low cost products.It is structured by Piezo-resistive ceramic pressure sensor as signal sensing element,adopt the special ASCI amplifier circuit and stainless steel housing,the XGZP6161 Transducer is integrally temperature compensated and linearity corrected,which effectively resist water hammer effect and transient over-voltage,etc. It can meet the requirement of measure and control under complex environment. Through strict component making, semi-finished product and all-finished product testing and aging, the Transducer is stable and reliable,having excellent consistency and sensitivity.
The XGZP6161 Transducer provide various output mode and pressure interface, the OEM service can meet extremely clients application requirement.
Pressure Range (100kPa=0.1mPa=1Bar≈14.5PSI)
Performance Parameter
Notes
1,Attention that the media should be compatible with the connected pressure parts.
2,Please contact us if special request on parameter and application.
Feature
Firm construction,Easy installation
0.5-4.5V output,Perfect performance.
Advanced Anti-interference,wave protection
Prefect Anti-shock,anti-overload,corrosion-resistant
Isolation Diaphragm,Ceramic Sensor element
Low cost for high volume application
Applications
Water pump,frequency-alterable constant voltage water supply,building automatic control, Water Treatment system,Hydraulic pressure monitoring etc,.
HVAC controlling(Heating, Ventilation and Air Conditioning),Air conditioner,Refrigeration, process controlling,hydraulic pressure monitoring ,etc.
Other pressure measure and control of petroleum,chemi-industry,metallurgy,power station, hydrology.etc,.
Introduction
XGZP6161 Pressure Transducer is high performance and low cost products.It is structured by Piezo-resistive ceramic pressure sensor as signal sensing element,adopt the special ASCI amplifier circuit and stainless steel housing,the XGZP6161 Transducer is integrally temperature compensated and linearity corrected,which effectively resist water hammer effect and transient over-voltage,etc. It can meet the requirement of measure and control under complex environment. Through strict component making, semi-finished product and all-finished product testing and aging, the Transducer is stable and reliable,having excellent consistency and sensitivity.
The XGZP6161 Transducer provide various output mode and pressure interface, the OEM service can meet extremely clients application requirement.
Pressure Range (100kPa=0.1mPa=1Bar≈14.5PSI)
| Range | Unit | Range | Unit | Range | Unit |
| 0 ~ 1 | mPa | 0 ~ 150 | PSI | 0 ~ 10 | Bar |
| 0 ~ 1.6 | mPa | 0 ~ 240 | PSI | 0 ~ 16 | Bar |
| 0 ~ 2 | mPa | 0 ~ 300 | PSI | 0 ~ 20 | Bar |
| 0 ~ 2.5 | mPa | 0 ~ 375 | PSI | 0 ~ 25 | Bar |
| 0 ~ 3 | mPa | 0 ~ 450 | PSI | 0 ~ 30 | Bar |
| Item | Data | Unit |
| Accuracy(non-lin., rep. and hys.) | ±1.0,±2.0 | %Span |
| Zero Thermal Drift | ±0.03 | %FS/ºC |
| Span Thermal Drift | ±0.03 | %FS/ºC |
| Long Term Stability(1 Year) | ±1 | %Span |
| Insulation Impedance(250Vdc) | 50 | MΩ |
| Over pressure | 2× | Rated |
| Burst Pressure | 3× | Rated |
| Pressure Circulation(Zero- Span) | 1 | Million |
| Compensation Temp. | 0 ~ 85/32~176 | ºC/ºF |
| Operating Temp. | 0 ~ 85/32~176 | ºC/ºF |
| Storage Temp. | -40 ~ 125/-40~257 | ºC/ºF |
| Housing Material | 304 Stainless Steel | |
| Socket Connector | Plastic | |
| Protection Grade | IP65 | |
| General condition:Power Input:3.3- 5.5VDC&Reference Temp.: (25±1)ºC/(77±1.8)ºF | ||
1,Attention that the media should be compatible with the connected pressure parts.
2,Please contact us if special request on parameter and application.
